Specs
SPECIFICATIONS
GXH50 | |
|---|---|
| Engine Type | Air-cooled 4-stroke OHV |
| Bore x Stroke | 41.8 X 36 mm |
| Displacement | 49.4 cm3 |
| Net Power Output* | 2.1 hp (1.6 kW) @ 7,000 rpm |
| Net Torque | 2.0 lb-ft (2.7 Nm) @ 4,500 rpm |
| PTO Shaft Rotation | Counterclockwise (from PTO shaft side) |
| Compression Ratio | 8.0:1 |
| Carburetor | Float Type |
| Ignition System | Transistorized magneto |
| Starting System | Recoil |
| Lubrication System | Forced splash |
| Governor System | Centrifugal Mechanical |
| Air Cleaner | Semi-dry |
| Oil Capacity | 0.26 US qt (0.25l) |
| Fuel | Unleaded 86 octane or higher |
| Fuel Tank Capacity | .81 U.S. qt (.77 liter) |
| Dry Weight | 12.1 lb (5.5 kg) |
DIMENSIONS
GXH50 | |
|---|---|
| Length (min) | 8.9" (225mm) |
| Width (min) | 10.8" (274mm) |
| Height (min) | 13.0" (353mm) |
PTO
GXH50 | ||
|---|---|---|
| Q type | Straight shaft | View Details |
