Specs
ZT7000 Key Specifications
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Mower Deck
AirFx Cutting System
AirFX Cutting System
AirFX™ Cutting System
AirFX™ Cutting System
Width
61 in
72 in
61 in
72 in
Cutting Height
1.5-5.5
1-5.5 in
1-5.5
1-5.5
Engine Model
Kaw FX1000 EFI
Kaw FX1000 EFI
Kaw FX1000V
Kaw FX1000V
Displacement
999 cm³
999 cm³
999 cm³
999 cm³
Transmission type
HG ZT-5400 2-Speed Hydrostatic Transaxles
HG ZT-5400 2-Speed Hydrostatic Transaxles
HG ZT-5400 2-Speed Hydrostatic Transaxles
HG ZT-5400 2-Speed Hydrostatic Transaxles
Pump Displacement
16 cm³
16 cm³
16 cm³
16 cm³
Deck
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Mower Deck
AirFx Cutting System
AirFX Cutting System
AirFX™ Cutting System
AirFX™ Cutting System
Width
61 in
72 in
61 in
72 in
Cutting Height
1.5-5.5
1-5.5 in
1-5.5
1-5.5
Blade Tip Speed
18,500 ft/min
18,152 ft/min
18,500 ft/min
18,152 ft/min
Discharge Chute
Flexible Molded Polymer
Flexible Molded Polymer
Flexible Molded Polymer
Flexible Molded Polymer
Engine
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Engine Model
Kaw FX1000 EFI
Kaw FX1000 EFI
Kaw FX1000V
Kaw FX1000V
Displacement
999 cm³
999 cm³
999 cm³
999 cm³
Fuel Capacity
15 gal
15 gal
15 gal
15 gal
Horsepower
38.5 hp
38.5 hp
35 hp
35 hp
Performance
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Weight
1500 lb
1541 lb
1500 lb
1541 lb
Transmission
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Transmission type
HG ZT-5400 2-Speed Hydrostatic Transaxles
HG ZT-5400 2-Speed Hydrostatic Transaxles
HG ZT-5400 2-Speed Hydrostatic Transaxles
HG ZT-5400 2-Speed Hydrostatic Transaxles
Pump Displacement
16 cm³
16 cm³
16 cm³
16 cm³
Oil Capacity
2.5 qt_liq_us
2.5 qt_liq_us
5.2 qt_liq_us
5.2 qt_liq_us
Forward Speed
13 mph
13 mph
13 mph
13 mph
Reverse Speed
5 mph
5 mph
5 mph
5 mph
Electrical
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Charging System
15 A
15 A
15 A
15 A
Clutch
250 ft·lbf
250 ft·lbf
250 ft·lbf
250 ft·lbf
Frame
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Front/Rear
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Length
87 in
87 in
87 in
87 in
Wheels
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Drive Wheel
26 x 12.0-12, 6-Spoke
26 x 12.0-12, 6-Spoke
26 x 12.0-12, 6-Spoke
26 x 12.0-12, 6-Spoke
Front Caster Wheel Size
15 x 6.5-6, No-Flat
15 x 6.5-6, No-Flat
15 x 6.5-6, No-Flat
15 x 6.5-6, No-Flat
Caster Arm Attachment
Bolt-On
Bolt-On
Bolt-On
Bolt-On
Seat
ZT7000 EFI - 61” Deck
ZT7000 EFI - 72” Deck
ZT7000 - 61” Deck
ZT7000 - 72” Deck
Seat
Extra-High Back, Full-Mechanical Suspension Seat
Extra-High Back, Full-Mechanical Suspension Seat
Extra-High Back, Full-Mechanical Suspension Seat
Extra-High Back, Full-Mechanical Suspension Seat
Fore-Aft Adjust
Seat Slide Lever
Seat Slide Lever
Seat Slide Lever
Seat Slide Lever
