Specs
ZT6000 Key Specifications
ZT6000 - 52” Deck <!-->
ZT6000 - 61” Deck -->
Mower Deck
AirFX™ Cutting System <!-->
AirFX™ Cutting System -->
Width
52 in
61 in
Cutting Height
1-5.5 in. <!-->
1-5.5 -->
Engine Model
Kaw FX801V <!-->
Kaw FX801V -->
Displacement
852 cm³
852 cm³
Transmission type
HG ZT-4400 Hydrostatic Transaxles <!-->
HG ZT-4400 Hydrostatic Transaxles -->
Pump Displacement
12 cm³
12 cm³
Deck
--> ZT6000 - 52” Deck <!-->
ZT6000 - 61” Deck -->
Mower Deck
AirFX™ Cutting System <!-->
AirFX™ Cutting System -->
Width
52 in
61 in
Cutting Height
1-5.5 in. <!-->
1-5.5 -->
Blade Tip Speed
18,586 ft/min
18,500 ft/min
Discharge Chute
Flexible Molded Polymer <!-->
Flexible Molded Polymer -->
Engine
<!--> ZT6000 - 52” Deck -->
ZT6000 - 61” Deck <!-->
Engine Model
Kaw FX801V -->
Kaw FX801V <!-->
Displacement
852 cm³
852 cm³
Fuel Capacity
15 gal
15 gal
Horsepower
25.5 hp
25.5 hp
Performance
--> ZT6000 - 52” Deck <!-->
ZT6000 - 61” Deck -->
Weight
1371 lb
1421 lb
Transmission
<!--> ZT6000 - 52” Deck -->
ZT6000 - 61” Deck <!-->
Transmission type
HG ZT-4400 Hydrostatic Transaxles -->
HG ZT-4400 Hydrostatic Transaxles <!-->
Pump Displacement
12 cm³
12 cm³
Oil Capacity
2.5 qt_liq_us
4.5 qt_liq_us
Forward Speed
12 mph
12 mph
Reverse Speed
4 mph -->
4 mph <!-->
Electrical
--> ZT6000 - 52” Deck <!-->
ZT6000 - 61” Deck -->
Charging System
15 A
15 A
Clutch
225 ft·lbf
225 ft·lbf
Frame
<!--> ZT6000 - 52” Deck -->
ZT6000 - 61” Deck <!-->
Front/Rear
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing -->
Welded 0.25 in, 7-gauge Steel; 1.5 x 2.5 in Steel Tubing <!-->
Length
83 in
83 in
Wheels
--> ZT6000 - 52” Deck <!-->
ZT6000 - 61” Deck -->
Drive Wheel
24 x 10.5-12 <!-->
24 x 10.5-12 -->
Front Caster Wheel Size
13 x 6.5-6 <!-->
13 x 6.5-6 -->
Caster Arm Attachment
Bolt On <!-->
Bolt-On -->
Seat
<!--> ZT6000 - 52” Deck -->
ZT6000 - 61” Deck <!-->
Seat
High-Back, Full-Mechanical Suspension Seat -->
High-Back, Full-Mechanical Suspension Seat <!-->
Fore-Aft Adjust
Seat Slide Lever -->
Seat Slide Lever <!-->
