Specs
ZT3500 Key Specifications
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Engine Model
Kaw FX651V
Kaw FX651V
Kaw FX651V
Displacement
726 cubic cm
726 cubic cm
726 cubic cm
Pump Displacement
12 cubic cm
12 cubic cm
12 cubic cm
Transmission Type
HG ZT-3400 Hydrostatic Transaxles
HG ZT-3400 Hydrostatic Transaxles
HG ZT-3400 Hydrostatic Transaxles
Cutting Height Range
1.5-4.9“ (38-124 mm)
1.5-4.875
1.5-4.875
Mower Deck
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts
TufDeck Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts
TufDeck Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts
Width
48 in
48 in
48 in
BobQuote
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Engine
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Fuel Tank
7.8 gal
7.8 gal
7.8 gal
Engine Model
Kaw FX651V
Kaw FX651V
Kaw FX651V
Horsepower
20.5 hp
21.5 hp
21.5 hp
Displacement
726 cubic cm
726 cubic cm
726 cubic cm
Performance
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Machine Weight - Wet
773 lbs
773 lbs
773 lbs
Price
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Power/Electrical
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Charging System
15 amp
15 amp
15 amp
Additional Product Information
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Transmission
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Pump Displacement
12 cubic cm
12 cubic cm
12 cubic cm
Transmission Type
HG ZT-3400 Hydrostatic Transaxles
HG ZT-3400 Hydrostatic Transaxles
HG ZT-3400 Hydrostatic Transaxles
Oil Capacity
4 qt
4 qt
4 qt
Travel Speed
10 mph
10 mph
10 mph
Travel Speed - Reverse
3.5 mph
3.5 mph
3.5 mph
Mower Seat
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Fore-Aft Adjustment
Seat Slide Lever
Seat Slide Lever
Seat Slide Lever
Description
High-Back, Mechanical Suspension Seat
High-Back, Spring Suspension Seat
High-Back, Spring Suspension Seat
Wheels
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Caster Arm
Welded to Frame
Welded to Frame
Welded to Frame
Front Caster Wheel Size
13 x 6.5-6
13 x 6.5-6
13 x 6.5-6
Drive Wheel Size
23 x 10.5-12
23 x 10.5-12
23 x 10.5-12
Frame
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Length
76 in
76 in
76 in
Front and Rear
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Welded 7-gauge Steel; 1.5 x 2.5 in Steel Tubing
Deck
ZT3500 - 48” Deck
ZT3500 - 52” Deck
ZT3500 - 61” Deck
Discharge Chute
Flexible Molded Polymer
Flexible Molded Polymer
Flexible Molded Polymer
Cutting Height Range
1.5-4.9“ (38-124 mm)
1.5-4.875
1.5-4.875
Mower Deck
TufDeck™ Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts
TufDeck Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts
TufDeck Pro 10-gauge Top with 7-gauge Spindle Supports; 7-gauge Side Skirts
Mower Blade Tip Speed
17365 ft/min
17365 ft/min
17365 ft/min
Width
48 in
48 in
48 in
