Specs
UV34XL Gas Key Specifications
UV34XL Gas
Operating Weight
2085 lbs
Travel Speed - High
35 mph
Cargo Box Bed Load Capacity
1250 lbs
Total Vehicle Rated Capacity
2075 lbs
Turning Radius
154 in
BobQuote
UV34XL Gas
Engine
UV34XL Gas
Horsepower
39.9 hp
Displacement
60.9 cubic in
Performance
UV34XL Gas
Operating Weight
2085 lbs
Travel Speed
35 mph
Travel Speed - High
35 mph
Travel Speed - Low
25 mph
Travel Speed - Reverse
25 mph
Capacities
UV34XL Gas
Fuel Tank
11.5 gal
Cargo Box Length
43.5 in
Cargo Box Width
54 in
Cargo Box Bed Load Capacity
1250 lbs
Cargo Box Height
11.5 in
Cargo Box Bed Load Height
38 in
Total Vehicle Rated Capacity
2075 lbs
Hydraulic System
UV34XL Gas
Dimension
UV34XL Gas
Length
155 in
Width
62 in
Height
76 in
Ground Clearance
11.7 in
Turning Radius
154 in
Wheelbase
117 in
Front Tire Size
26x10-12
Rear Tire Size
26x10-12
Controls
UV34XL Gas
Features
UV34XL Gas
Joystick Control
Not Applicable
Hydrostatic Transmission
Not Applicable
Front and Rear Work Lights
Optional
Air Conditioning
Not Applicable
Backup Alarm
Optional
BICS System (Interlock)
Not Applicable
Cab Enclosure
Optional
Sound Option
Not Applicable
Cab Heater
Optional
Heater Air Conditioning
Not Applicable
Operating Lights
Optional
Washer/Wiper (Front Rear and Roof)
Optional
Selectable 4 wheel drive
N/A
Spark Arrestor Muffler
Standard
Tilt Steering Wheel
Standard
Safety Seat Switch
Not Applicable
Cup Holder
Standard
Tail Lights
Standard
Brake Lights
Standard
Drive System
UV34XL Gas
Main Drive
CVT-Automatic
Price
UV34XL Gas
Additional Product Information
UV34XL Gas
