Specs
UT6066 Key Specifications
UT6066
Horsepower
66.4 hp
Lift Capacity at 24" behind Lift Point
3,898 lb
PTO HP
53.6 hp
Transmission Type
3 Range Powershuttle (w/electronic clutch)
Width
77.2 in
Turning Radius
12' 3"
Wheelbase
6' 10"
Engine
UT6066
Emissions Tier (EPA)
Tier 4
Horsepower
66.4 hp
Displacement
149 in³
Number of Cylinders
4
Engine Model
4HT-TP4A
Performance
UT6066
Operating Weight
5,440 lb
Tractor Operating Weight
5,440 lb
Travel Speed
19.8 mph
Travel Speed - Reverse
19.5 mph
3-Point Hitch
Category 2
3-pt Lift Control Type
Position with Draft Control
Lift Capacity at 24" behind Lift Point
3,898 lb
Rear PTO System
Independent
Rear PTO - RPM
540
PTO HP
53.6 hp
Capacities
UT6066
Fuel Tank
22.45 gal
Hydraulic System
UT6066
Implement Hydraulic Flow
10.99 gal/min
Total Hydraulic Flow
17.86 gal/min
Steering Hydraulic Flow
6.87 gal/min
Drive System
UT6066
Brake Type
Wet Multi Disc
Transmission Type
3 Range Powershuttle (w/electronic clutch)
Dimension
UT6066
Length
148.8 in
Width
77.2 in
Height
102.1 in
Ground Clearance
12.3 in
Turning Radius
12' 3"
Wheelbase
6' 10"
Front Tire Size
Front Industrial (AG, multi-use) 12.5/80-18 (9.5-24, 340/80R18)
Rear Tire Size
Rear Industrial (AG, multi-use) 18.4-24 (16.9-30, 480/80R26)
Loader Attachment
UT6066
Loader Lift Height
10' 9"
Lift Capacity at Bucket Pivot
3,017 lb
Bucket Width
6' 9"
