Specs
TL723 Key Specifications
TL723 <!-->
Horsepower
100 hp
Operating Weight
16163 lb
Rated Capacity
7718 lb
Lift Height
274 in
Rated Capacity @ Full Height
7718 lb
Auxiliary Std Flow
26.4 gal/min
Engine
<!--> TL723 -->
Emissions Tier (EPA)
Tier 4 <!-->
Engine Cooling
Liquid -->
Engine Fuel
Diesel <!-->
Horsepower
100 hp
Displacement
207 in³
Turbocharged Engine
yes -->
Performance
<!--> TL723 -->
Operating Weight
16163 lb
Travel Speed - High
24.8 mph
Travel Speed - Low
3.7 mph
Rated Capacity
7718 lb
Lift Height
274 in
Lift Height @ Rated Capacity
274 in
Max Reach
157.6 in
Rated Capacity @ Full Height
7718 lb
Rated Capacity @ Max Reach
3308 lb
Bucket Breakout Force
13,938 lbf
Max Draw Bar Pull
15062 lb
Boom Breakout Force
8,093 lbf
Hydraulic System
<!--> TL723 -->
Auxiliary Std Flow
26.4 gal/min
Auxiliary Pressure
3,626 psi
Dimension
<!--> TL723 -->
Length
239.1 in
Length Fork Heel To Rear
191.9 in
Width
90.6 in
Height
96.7 in
Height with Operator Cab
96.7 in
Cab Height with Beacon
101.9 in
Wheelbase
113 in
Features
<!--> TL723 -->
Hydrostatic Transmission
Standard <!-->
Enclosed Operator Cab (ROPS/FOPS)
Standard -->
Heater Air Conditioning
Standard <!-->
Operating Lights
Standard -->
Quick Tach System
Not Applicable <!-->
Auxiliary Hydraulics
Standard -->
Joystick Control
Standard <!-->
Power Qtach
Standard -->
