Specs
T770 Key Specifications
T770
Rated Operating Capacity (ISO)
3,475 lb
Operating Weight
10515 lb
Ground Pressure (Rubber)
4.2 psi
Auxiliary Std Flow
23 gal/min
Auxiliary High Flow
36.6 gal/min
Joystick Control
Optional
Engine
T770
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
92 hp
Turbocharged Engine
yes
Performance
T770
Rated Operating Capacity (ISO)
3,475 lb
Operating Capacity (50% of Tip)
4960 lb
Tipping Load
9929 lb
Operating Weight
10515 lb
Travel Speed
6.6 mph
Travel Speed (2-speed option)
10.7 mph
Ground Pressure (Rubber)
4.2 psi
Capacities
T770
Fuel Tank
43.8 gal
Hydraulic System
T770
System Relief @ Quick Couplers
3,500 psi
Auxiliary Std Flow
23 gal/min
Auxiliary High Flow
36.6 gal/min
Dimension
T770
Length
141.6 in
Length without Attachment
114.3 in
Length with Standard Bucket
141.6 in
Width
78 in
Width (with bucket)
80 in
Height
81.3 in
Height with Operator Cab
81.3 in
Height to Bucket Hinge Pin
131.4 in
Reach @ Maximum Height
35.2 in
Turning Radius
88 in
Length of track on ground
63.7 in
Track Width
17.7 in
Features
T770
Joystick Control
Optional
Air Conditioning
Optional
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Heater
Optional
Operating Lights
Standard
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Optional
Ride Control
Optional
Horn
Standard
Cab Enclosure
Optional
Adjustable Seat
Standard
Sound Option
Optional
Rear Window
Standard
Top Window
Standard
Seat Belt
Standard
Spark Arrestor Muffler
Standard
