Specs
T76 Key Specifications
T76
Rated Operating Capacity (ISO)
2900 lbs
Operating Weight
10250 lbs
Ground Pressure (Rubber)
6.2 psi
Auxiliary Std Flow
23.3 gpm
Auxiliary High Flow
30.3 gpm
Joystick Control
Standard
BobQuote
T76
SSL Specs
T76
Engine
T76
Horsepower
74 hp
Gross HP
74.1 hp
Net HP
70.5 hp
Starter Horsepower
4 hp
Fuel Consumption
2.9 gpm
Turbocharged Engine
yes
Performance
T76
Rated Operating Capacity (ISO)
2900 lbs
Operating Capacity (50% of Tip)
4143 lbs
Tipping Load
8285 lbs
Operating Weight
10250 lbs
Travel Speed
6.8 mph
Travel Speed (2-speed option)
9.2 mph
Ground Pressure (Rubber)
6.2 psi
Capacities
T76
Fuel Tank
31.7 gal
Cooling System
11.2 qt
Engine Oil with Filter
9.7 qt
Hydraulic Reservoir
20 qt
Hyd System Capacity
13.5 gal
Hydraulic System
T76
Pump Capacity
23.3 gpm
System Relief @ Quick Couplers
3500 psi
Auxiliary Std Flow
23.3 gpm
Auxiliary High Flow
30.3 gpm
Raise Lift Arm
4.3 sec
Lower Lift Arm
2.9 sec
Bucket Dump
2.1 sec
Bucket Rollback
1.6 sec
Dimension
T76
Length
147.1 in
Length without Attachment
113.9 in
Length with Standard Bucket
147.1 in
Width
72.9 in
Width (with bucket)
74 in
Height
81.8 in
Height with Operator Cab
81.8 in
Height to Bucket Hinge Pin
128.3 in
Operating Height
167.4 in
Max Dump Height
99.1 in
Reach @ Maximum Height
39.9 in
Angle of Departure
27 deg
Rollback Angle
31 deg
Turning Radius
89.3 in
Length of track on ground
59.2 in
Track Width
12.6 in
Track Width - Optional
17.7 in
Overall Width
78 in
Controls
T76
Vehicle Steering
Selectable Joystick Control
Throttle
Dial and Foot
Instrumentation
T76
Features
T76
Joystick Control
Standard
Front and Rear Work Lights
Standard
Heated Cloth Air-Ride Seat
Standard
Air Conditioning
Standard
5-Link Torsion Suspension Undercarriage
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Standard
ROPS/FOPS Approved
ROPS Level 1 Standard; ROPS Level 2 Optional
ROPS-Step
N/A
Sound Option
Standard
Cab Heater
Standard
Heater Air Conditioning
Optional
Operating Lights
Standard
Work Lights
Standard
Radio
Optional
Rear Window
Standard
Top Window
Standard
Lift-Arm Support
Standard
Grab Handles
N/A
Seat Belt
Standard 2-Point Lap Belt with Suspension Seat and Standard 3-Point Shoulder Belt with Heated Cloth Air Ride Seat on Two-Speed Models
Seat Bar
One Piece Rollup
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Lockable Ignition
N/A
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Standard
High Flow Option
Optional
Auxiliary Hydraulics
Standard
3-Spool Valve
N/A
Grease Track Tension
Standard
Purifier Muffler Opt
Not Applicable
Spark Arrestor Muffler
DOC
Bob-Tach Attachment System
Standard
Power Bob-Tach
Standard
ACS (Switchable Controls)
Not Applicable
Ride Control
Optional
Rear Hydraulics
Optional
Horn
Standard
Operation Cost
T76
Serviceability
T76
Grease Interval (hrs)
10 hr
Drive System
T76
Chain Master Link
N/A
Price
T76
Additional Product Information
T76
