Specs
T740 Key Specifications
T740
Rated Operating Capacity (ISO)
3200 lbs
Operating Weight
10127 lbs
Ground Pressure (Rubber)
4.1 psi
Joystick Control
Standard
BobQuote
T740
SSL Specs
T740
Engine
T740
Horsepower
74 hp
Starter Horsepower
3.6 hp
Fuel Consumption
4.4 gph
Turbocharged Engine
yes
Performance
T740
Rated Operating Capacity (ISO)
3200 lbs
Operating Capacity (50% of Tip)
4571 lbs
Tipping Load
9143 lbs
Operating Weight
10127 lbs
Travel Speed
6 mph
Travel Speed (2-speed option)
8.3 mph
Ground Pressure (Rubber)
4.1 psi
Capacities
T740
Fuel Tank
43.8 gal
Hydraulic System
T740
Hydraulic High Flow (optional)
30.5 gpm
Hydraulic Standard Flow
23 gpm
System Relief @ Quick Couplers
3500 psi
Dimension
T740
Length
114.3 in
Length without Attachment
114.3 in
Length with Standard Bucket
141.6 in
Width
78 in
Width (with bucket)
80 in
Height with Operator Cab
81.3 in
Height to Bucket Hinge Pin
131 in
Operating Height
82 in
Reach @ Maximum Height
35.2 in
Turning Radius
88 in
Length of track on ground
63.7 in
Track Width
17.7 in
Controls
T740
Instrumentation
T740
Features
T740
Joystick Control
Standard
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
ROPS-Step
N/A
Cab Heater
Optional
Operating Lights
Standard
Rear Window
Standard
Top Window
Standard
Grab Handles
N/A
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Lockable Ignition
N/A
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
3-Spool Valve
N/A
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
Ride Control
Optional
Horn
Standard
Operation Cost
T740
Serviceability
T740
Drive System
T740
Chain Master Link
N/A
Price
T740
Additional Product Information
T740
