Specs
T66 Key Specifications
T66
Rated Operating Capacity (ISO)
2450 lbs
Operating Weight
8840 lbs
Ground Pressure (Rubber)
5.8 psi
Auxiliary Std Flow
17.6 gpm
Auxiliary High Flow
26.9 gpm
Joystick Control
Optional
BobQuote
T66
SSL Specs
T66
Engine
T66
Horsepower
74 hp
Gross HP
74 hp
Net HP
70.5 hp
Starter Horsepower
3.6 hp
Fuel Consumption
2.9 gph
Turbocharged Engine
yes
Performance
T66
Rated Operating Capacity (ISO)
2450 lbs
Operating Capacity (50% of Tip)
3500 lbs
Tipping Load
7000 lbs
Operating Weight
8840 lbs
Travel Speed
7.2 mph
Travel Speed (2-speed option)
10.2 mph
Ground Pressure (Rubber)
5.8 psi
Capacities
T66
Fuel Tank
28.3 gal
Cooling System
11.2 qt
Engine Oil with Filter
9.7 qt
Hydraulic Reservoir
20 qt
Hyd System Capacity
13.6 gal
Hydraulic System
T66
Pump Capacity
17.6 gpm
System Relief @ Quick Couplers
3500 psi
Auxiliary Std Flow
17.6 gpm
Auxiliary High Flow
26.9 gpm
Raise Lift Arm
3.8 sec
Lower Lift Arm
2.2 sec
Bucket Dump
2.3 sec
Bucket Rollback
1.6 sec
Dimension
T66
Length
134.9 in
Length without Attachment
107 in
Length with Standard Bucket
134.9 in
Width
67 in
Width (with bucket)
68 in
Height
80.5 in
Height with Operator Cab
80.5 in
Height to Bucket Hinge Pin
120 in
Operating Height
153.9 in
Max Dump Height
94.3 in
Reach @ Maximum Height
36.7 in
Angle of Departure
25 deg
Rollback Angle
31 deg
Turning Radius
81.5 in
Length of track on ground
54.3 in
Track Width
12.6 in
Track Width - Optional
15.7 in
Overall Width
68 in
Controls
T66
Vehicle Steering
Dual Levers
Throttle
Dial type on Right Front Post
Instrumentation
T66
Features
T66
Joystick Control
Optional
Front and Rear Work Lights
Standard
Air Conditioning
Optional
5-Link Torsion Suspension Undercarriage
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
ROPS/FOPS Approved
Level 1
ROPS-Step
N/A
Sound Option
Optional
Cab Heater
Optional
Heater Air Conditioning
Optional
Operating Lights
Standard
Work Lights
Standard
Radio
Optional
Rear Window
Standard
Top Window
Standard
Lift-Arm Support
Standard
Grab Handles
N/A
Seat Belt
Standard 2-Point Lap Belt and Optional 3-Point Shoulder Belt on Two-Speed Models
Seat Bar
Standard
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Lockable Ignition
N/A
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
3-Spool Valve
N/A
Grease Track Tension
Standard
Purifier Muffler Opt
Not Applicable
Spark Arrestor Muffler
DOC
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
Ride Control
Optional
Rear Hydraulics
Optional
Horn
Standard
Operation Cost
T66
Serviceability
T66
Drive System
T66
Chain Master Link
N/A
