Specs
T650 Key Specifications
T650
Rated Operating Capacity (ISO)
2,570 lb
Operating Weight
9113 lb
Ground Pressure (Rubber)
5.7 psi
Auxiliary Std Flow
23 gal/min
Joystick Control
Optional
Engine
T650
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
74 hp
Turbocharged Engine
yes
Performance
T650
Rated Operating Capacity (ISO)
2,570 lb
Operating Capacity (50% of Tip)
3670 lb
Tipping Load
7343 lb
Operating Weight
9113 lb
Travel Speed
6.2 mph
Travel Speed (2-speed option)
8.7 mph
Ground Pressure (Rubber)
5.7 psi
Capacities
T650
Fuel Tank
43.9 gal
Hydraulic System
T650
System Relief @ Quick Couplers
3,500 psi
Auxiliary Std Flow
23 gal/min
Dimension
T650
Length
136.8 in
Length without Attachment
108.4 in
Width
72.9 in
Width (with bucket)
74 in
Height with Operator Cab
81.3 in
Height to Bucket Hinge Pin
124 in
Reach @ Maximum Height
36 in
Length of track on ground
57.7 in
Track Width
12.6 in
Features
T650
Joystick Control
Optional
Air Conditioning
Optional
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Heater
Optional
Operating Lights
Standard
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
Horn
Standard
Cab Enclosure
Optional
Adjustable Seat
Standard
Sound Option
Optional
Rear Window
Standard
Top Window
Standard
Seat Belt
Standard
Spark Arrestor Muffler
Standard
Lift-Arm Support
Standard
