Specs
T595 Key Specifications
T595
Rated Operating Capacity (ISO)
2100 lbs
Operating Weight
7822 lbs
Ground Pressure (Rubber)
5.1 psi
Auxiliary Std Flow
17.1 gpm
Auxiliary High Flow
26.7 gpm
Joystick Control
Standard
BobQuote
T595
SSL Specs
T595
Engine
T595
Horsepower
70 hp
Gross HP
70 hp
Net HP
66.7 hp
Starter Horsepower
4.3 hp
Fuel Consumption
3.7 gph
Turbocharged Engine
yes
Performance
T595
Rated Operating Capacity (ISO)
2100 lbs
Operating Capacity (50% of Tip)
3142 lbs
Tipping Load
6517 lbs
Operating Weight
7822 lbs
Travel Speed
7.1 mph
Ground Pressure (Rubber)
5.1 psi
Capacities
T595
Fuel Tank
36.5 gal
Cooling System
2.9 gal
Engine Oil with Filter
9.1 qt
Hydraulic Reservoir
2 gal
Hyd System Capacity
9.5 gal
Hydraulic System
T595
Pump Capacity
17.1 gpm
System Relief @ Quick Couplers
3550 psi
Auxiliary Std Flow
17.1 gpm
Auxiliary High Flow
26.7 gpm
Raise Lift Arm
3.8 sec
Lower Lift Arm
2.5 sec
Bucket Dump
2.3 sec
Bucket Rollback
1.7 sec
Dimension
T595
Length
133 in
Length without Attachment
104.5 in
Length with Standard Bucket
133 in
Width
67 in
Width (with bucket)
68 in
Width (over tires)
0 in
Height
77.8 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
119 in
Operating Height
149.1 in
Max Dump Height
86.8 in
Reach @ Maximum Height
34.9 in
Angle of Departure
27.8 deg
Rollback Angle
30 deg
Turning Radius
80 in
Length of track on ground
54.1 in
Track Width
12.6 in
Track Width - Optional
15.7 in
Overall Width
67 in
Controls
T595
Vehicle Steering
Dual Levers
Instrumentation
T595
Features
T595
Joystick Control
Standard
Front and Rear Work Lights
Standard
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
ROPS/FOPS Approved
Standard
ROPS-Step
N/A
Sound Option
Optional
Cab Heater
Optional
Heater Air Conditioning
Optional
Operating Lights
Standard
Work Lights
Standard
Rear Window
Standard
Top Window
Standard
Grab Handles
N/A
Seat Belt
Standard
Seat Bar
Standard
Suspension Seat
Standard
Two Speed Travel
Not Applicable
Deluxe Instrumentation
Optional
Lockable Ignition
N/A
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
3-Spool Valve
N/A
Grease Track Tension
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Not Applicable
Ride Control
Optional
Horn
Standard
Operation Cost
T595
Serviceability
T595
Drive System
T595
Chain Master Link
N/A
Price
T595
Additional Product Information
T595
