Specs
T550 Key Specifications
T550
Rated Operating Capacity (ISO)
1,995 lb
Operating Weight
7557 lb
Ground Pressure (Rubber)
4.9 psi
Auxiliary Std Flow
17.1 gal/min
Joystick Control
Optional
Engine
T550
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
68 hp
Turbocharged Engine
yes
Performance
T550
Rated Operating Capacity (ISO)
1,995 lb
Operating Capacity (50% of Tip)
2850 lb
Tipping Load
5700 lb
Operating Weight
7557 lb
Travel Speed
7.1 mph
Ground Pressure (Rubber)
4.9 psi
Capacities
T550
Fuel Tank
36.5 gal
Hydraulic System
T550
System Relief @ Quick Couplers
3,500 psi
Auxiliary Std Flow
17.1 gal/min
Dimension
T550
Length
133 in
Length without Attachment
104.5 in
Length with Standard Bucket
133 in
Width
67 in
Width (with bucket)
68 in
Height
77.8 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
114.5 in
Reach @ Maximum Height
18.4 in
Turning Radius
80 in
Length of track on ground
54.1 in
Track Width
12.6 in
Track Width - Optional
15.7 in
Features
T550
Joystick Control
Optional
Air Conditioning
Optional
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Heater
Optional
Operating Lights
Standard
Suspension Seat
Standard
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
Ride Control
Not Applicable
Horn
Standard
Cab Enclosure
Optional
Adjustable Seat
Standard
Sound Option
Optional
Rear Window
Standard
Top Window
Standard
Seat Belt
Standard
Spark Arrestor Muffler
Standard
