Specs
T450 Key Specifications
T450
Rated Operating Capacity (ISO)
1490 lbs
Operating Weight
6424 lbs
Ground Pressure (Rubber)
4.8 psi
Auxiliary Std Flow
16.7 gpm
Joystick Control
Optional
Engine
T450
Horsepower
55 hp
Performance
T450
Rated Operating Capacity (ISO)
1490 lbs
Operating Capacity (50% of Tip)
2120 lbs
Tipping Load
4257 lbs
Operating Weight
6424 lbs
Travel Speed
7 mph
Travel Speed (2-speed option)
11 mph
Ground Pressure (Rubber)
4.8 psi
Capacities
T450
Fuel Tank
17.1 gal
Hydraulic System
T450
System Relief @ Quick Couplers
3300 psi
Auxiliary Std Flow
16.7 gpm
Dimensions
T450
Length
98.4 in
Length without Attachment
98.4 in
Length with Standard Bucket
126.6 in
Width
55 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
109.5 in
Reach @ Maximum Height
23.5 in
Turning Radius
77.9 in
Length of track on ground
50.2 in
Track Width
11.8 in
Controls
T450
Serviceability
T450
Price
T450
Additional Product Information
T450
Features
T450
Joystick Control
Optional
Air Conditioning
Optional
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
ROPS/FOPS Approved
Standard
ROPS-Step
N/A
Sound Option
Optional
Cab Heater
Optional
Heater Air Conditioning
Optional
Operating Lights
Standard
Work Lights
Standard
Rear Window
Standard
Top Window
Standard
Grab Handles
N/A
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Not Applicable
Deluxe Instrumentation
Optional
Lockable Ignition
N/A
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Not Applicable
Auxiliary Hydraulics
Standard
3-Spool Valve
N/A
Grease Track Tension
Standard
Purifier Muffler Opt
Not Applicable
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Not Applicable
Ride Control
Not Applicable
Horn
Standard
