Specs
S650 Key Specifications
S650
Horsepower
74 hp
Rated Operating Capacity (ISO)
2690 lbs
Operating Weight
8061 lbs
Auxiliary Std Flow
23 gpm
Joystick Control
Optional
BobQuote
S650
SSL Specs
S650
Engine
S650
Horsepower
74 hp
Turbocharged Engine
yes
Performance
S650
Rated Operating Capacity (ISO)
2690 lbs
Tipping Load
5380 lbs
Operating Weight
8061 lbs
Travel Speed
7.1 mph
Travel Speed (2-speed option)
12.3 mph
Capacities
S650
Fuel Tank
23.9 gal
Hydraulic System
S650
System Relief @ Quick Couplers
3500 psi
Auxiliary Std Flow
23 gpm
Dimension
S650
Length
136.8 in
Length without Attachment
108.4 in
Length with Standard Bucket
136.8 in
Width
72.1 in
Width (with bucket)
74 in
Height with Operator Cab
81.3 in
Height to Bucket Hinge Pin
124 in
Reach @ Maximum Height
31.5 in
Angle of Departure
25.2 deg
Turning Radius
82.9 in
Wheelbase
45.3 in
Controls
S650
Instrumentation
S650
Features
S650
Joystick Control
Optional
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Sound Option
Optional
Cab Heater
Optional
Operating Lights
Standard
Parking Brake
Standard
Radio
Optional
Rear Window
Standard
Top Window
Standard
Lift-Arm Support
Standard
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Standard
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
Ride Control
Optional
Rear Hydraulics
Optional
Horn
Standard
Serviceability
S650
Drive System
S650
Price
S650
Flail Mower Specs
S650
Additional Product Information
S650
