Specs
S64 Key Specifications
S64
Horsepower
68 hp
Rated Operating Capacity (ISO)
2300 lbs
Operating Weight
6974 lbs
Auxiliary Std Flow
17.6 gpm
Auxiliary High Flow
26.9 gpm
Joystick Control
Optional
Engine
S64
Horsepower
68 hp
Performance
S64
Rated Operating Capacity (ISO)
2300 lbs
Rated Operating Capacity 200 lb. Counterweight
2450 lbs
Tipping Load
4600 lbs
Operating Weight
6974 lbs
Travel Speed
7.4 mph
Travel Speed (2-speed option)
11 mph
Capacities
S64
Fuel Tank
28.3 gal
Hydraulic System
S64
System Relief @ Quick Couplers
3500 psi
Auxiliary Std Flow
17.6 gpm
Auxiliary High Flow
26.9 gpm
Dimensions
S64
Length without Attachment
107 in
Length with Standard Bucket
135 in
Width
64.6 in
Width (with bucket)
68 in
Height with Operator Cab
80.5 in
Height to Bucket Hinge Pin
120 in
Reach @ Maximum Height
34.2 in
Turning Radius
80.1 in
Wheelbase
44.6 in
Controls
S64
Instrumentation
S64
Price
S64
Additional Product Information
S64
Features
S64
Joystick Control
Optional
Dual-Direction Bucket Positioning
Optional
Heated Cloth Air-Ride Seat
Optional
LED Front and Rear Lights
Standard
Radio Remote Control (SJC Required)
Optional
Reversing Fan
Optional
Speed Management
Included with SJC Option
Standard Display (includes keyless start)
Standard
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Sound Option
Optional
Cab Heater
Optional
Operating Lights
Standard
Parking Brake
Wedge Brake System
Radio
Optional
Rear Window
Standard
Top Window
Standard
Lift-Arm Support
Standard
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Standard
Deluxe Instrumentation
Not Applicable
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Not Applicable
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
DOC
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Not Applicable
Ride Control
Optional
Rear Hydraulics
Optional
Horn
Standard
