Specs
S590 Key Specifications
S590
Horsepower
68 hp
Rated Operating Capacity (ISO)
2,100 lb
Operating Weight
6765 lb
Auxiliary Std Flow
17.1 gal/min
Auxiliary High Flow
26.7 gal/min
Joystick Control
Optional
Engine
S590
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
68 hp
Turbocharged Engine
yes
Performance
S590
Rated Operating Capacity (ISO)
2,100 lb
Tipping Load
4000 lb
Operating Weight
6765 lb
Travel Speed
7 mph
Travel Speed (2-speed option)
11.4 mph
Capacities
S590
Fuel Tank
24.8 gal
Hydraulic System
S590
System Relief @ Quick Couplers
3,500 psi
Auxiliary Std Flow
17.1 gal/min
Auxiliary High Flow
26.7 gal/min
Dimension
S590
Length
133 in
Length without Attachment
104.6 in
Length with Standard Bucket
133 in
Width
65.2 in
Width (with bucket)
68 in
Height
77.8 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
119 in
Reach @ Maximum Height
32.6 in
Turning Radius
79.7 in
Wheelbase
42.6 in
Features
S590
Joystick Control
Optional
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Sound Option
Optional
Cab Heater
Optional
Operating Lights
Standard
Parking Brake
Standard
Radio
Optional
Rear Window
Standard
Top Window
Standard
Lift-Arm Support
Standard
Seat Belt
Standard
Suspension Seat
Standard
Two Speed Travel
Standard
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Optional
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Not Applicable
Ride Control
Optional
Rear Hydraulics
Optional
Horn
Standard
Tires
S590
