Specs
S450 Key Specifications
S450
Horsepower
49 hp
Rated Operating Capacity (ISO)
1,370 lb
Operating Weight
5370 lb
Auxiliary Std Flow
16.7 gal/min
Joystick Control
Optional
Engine
S450
Emissions Tier (EPA)
Tier 4
Engine Cooling
Liquid
Engine Fuel
Diesel
Horsepower
49 hp
Turbocharged Engine
yes
Performance
S450
Rated Operating Capacity (ISO)
1,370 lb
Tipping Load
2740 lb
Operating Weight
5370 lb
Travel Speed
7.6 mph
Travel Speed (2-speed option)
9.2 mph
Capacities
S450
Fuel Tank
14.2 gal
Hydraulic System
S450
System Relief @ Quick Couplers
3,300 psi
Auxiliary Std Flow
16.7 gal/min
Dimension
S450
Length
98.4 in
Length without Attachment
98.4 in
Length with Standard Bucket
124.9 in
Width
58.6 in
Width (with bucket)
62 in
Height
77.8 in
Height with Operator Cab
77.8 in
Height to Bucket Hinge Pin
109.5 in
Reach @ Maximum Height
20.8 in
Turning Radius
76.4 in
Wheelbase
35.4 in
Features
S450
Joystick Control
Optional
Air Conditioning
Optional
Adjustable Seat
Standard
Backup Alarm
Standard
BICS System (Interlock)
Standard
Cab Enclosure
Optional
Sound Option
Optional
Cab Heater
Optional
Operating Lights
Standard
Parking Brake
Standard
Radio
Optional
Rear Window
Standard
Top Window
Standard
Lift-Arm Support
Standard
Seat Belt
Standard
Suspension Seat
Optional
Two Speed Travel
Optional
Deluxe Instrumentation
Optional
Engine Shutdown
Standard
Hydraulic Bucket Positioning
Optional
High Flow Option
Not Applicable
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Power Bob-Tach
Optional
ACS (Switchable Controls)
Not Applicable
Ride Control
Optional
Rear Hydraulics
Optional
Horn
Standard
Tires
S450
