Specs
PG570 Key Specifications
PG570
Runtime Hours @ 75% Load
27.8
Power Output @ 1800RPM
680 hp
Engine
PG570
Engine Make
Cummins
Displacement
15 l
Emissions Tier Level
Tier 4 Final
Aftertreatment Technology
SCR
Capacities
PG570
Diesel Exhaust Fluid (DEF) Capacity
46 gal
Fuel Tank Capacity
656 gal
Dimensions
PG570
Length
260 in
Width
98.5 in
Height
119.8 in
Prime Power Rating
PG570
@ 480V-3-phase, 0.8PF, 60Hz
570 kVA (456 kW), 686 Amps
@ 240V-3-phase, 0.8PF, 60Hz
570 kVA (456 kW), 1371 Amps
@ 208V-3-phase, 0.8PF, 60Hz
570 kVA (456 kW), 1582 Amps
@ 240V-single-phase, 1.0PF, 60Hz
255 kVA (255 kW), 1063 Amps
@ 120V-single-phase, 1.0PF, 60Hz
255 kVA (255 kW), 1063 x 2 Amps
Voltage Configuration
Link Board
Runtime Hours @ 75% Load
27.8
Sound Level
75 dB(A)
Frequency Capability
60Hz
Power Output @ 1800RPM
680 hp
