Specs
PG50 Key Specifications
PG50
Runtime Hours @ 75% Load
40.3
Power Output @ 1800RPM
62.2 hp
Engine
PG50
Engine Make
Doosan
Displacement
2.4 l
Emissions Tier Level
Tier 4 Final
Capacities
PG50
Fuel Tank Capacity
102 gal
Dimensions
PG50
Length
130.5 in
Width
68.3 in
Height
76.6 in
Prime Power Rating
PG50
@ 480V-3-phase, 0.8PF, 60Hz
50 kVA (40 kW), 60 Amps
@ 240V-3-phase, 0.8PF, 60Hz
50 kVA (40 kW), 120 Amps
@ 208V-3-phase, 0.8PF, 60Hz
50 kVA (40 kW), 139 Amps
@ 240V-single-phase, 1.0PF, 60Hz
33 kVA (33 kW), 140 Amps
@ 120V-single-phase, 1.0PF, 60Hz
33 kVA (33 kW), 140 x 2 Amps
@ 400V-3-phase, 0.8PF, 50H
43 kVA (34 kW), 62 Amps
Voltage Configuration
3-Position Switch
Runtime Hours @ 75% Load
40.3
Sound Level
66 dB(A)
Frequency Capability
50Hz/60Hz Switchable
Power Output @ 1800RPM
62.2 hp
