Specs
PG400 Key Specifications
PG400
Runtime Hours @ 75% Load
27
Power Output @ 1800RPM
475 hp
Engine
PG400
Engine Make
Cummins
Displacement
11.8 l
Emissions Tier Level
Tier 4 Final
Aftertreatment Technology
DOC / SCR / DPF
Capacities
PG400
Diesel Exhaust Fluid (DEF) Capacity
46 gal
Fuel Tank Capacity
470 gal
Dimensions
PG400
Length
241 in
Width
83 in
Height
115 in
Prime Power Rating
PG400
@ 480V-3-phase, 0.8PF, 60Hz
402 kVA (321 kW), 484 Amps
@ 240V-3-phase, 0.8PF, 60Hz
402 kVA (321 kW), 969 Amps
@ 208V-3-phase, 0.8PF, 60Hz
402 kVA (321 kW), 1118 Amps
@ 240V-single-phase, 1.0PF, 60Hz
216 kVA (216 kW), 900 Amps
@ 120V-single-phase, 1.0PF, 60Hz
216 kVA (216 kW), 900 x 2 Amps
@ 400V-3-phase, 0.8PF, 50H
387 kVA (310 kW), 559 Amps
Voltage Configuration
Link Board
Runtime Hours @ 75% Load
27
Sound Level
76 dB(A)
Frequency Capability
50Hz/60Hz Switchable
Power Output @ 1800RPM
475 hp
