Specs
MT120 Key Specifications
MT120
Rated Operating Capacity with Bucket (Straight)
1200 lbs
Operating Weight
3720 lbs
Auxiliary Std Flow
11.8 gpm
Width
35.59 in
Height to Bucket Hinge Pin
88.2 in
Engine
MT120
Horsepower
24.5 hp
Displacement
75 cubic in
Number of Cylinders
3
Performance
MT120
Rated Operating Capacity with Bucket (Straight)
1200 lbs
Ground Pressure (Standard Tracks)
4.3 psi
Ground Pressure (Optional Tracks)
3.9 psi
Tipping Load
3469 lbs
Operating Weight
3720 lbs
Travel Speed - Forward
4.7 mph
Travel Speed - Reverse
4.7 mph
Capacities
MT120
Fuel Tank
8.1 gal
Hydraulic System
MT120
Pump Capacity
12 gpm
System Relief @ Quick Couplers
3045 psi
Auxiliary Std Flow
11.8 gpm
Dimensions
MT120
Length
107.34 in
Width
35.59 in
Height
57.63 in
Height to Bucket Hinge Pin
88.2 in
Reach @ Maximum Height
22.2 in
Length of track on ground
55.7 in
Track Width - Wide
11 in
Track Width - Standard
9.1 in
Controls
MT120
Instrumentation
MT120
Drive System
MT120
Price
MT120
Additional Product Information
MT120
Features
MT120
Lift-Arm Support
Standard
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Optional
Common Industry Interface
Optional
Wide Track
Optional
Neutral Start Interlocks
Not Applicable
Lift Arm Lockout With Manual Bypass
Standard
Tilt Lockout
Standard
Built-In Tie Down & Crane/Lift Locations
Standard
