Specs
MT100 Key Specifications
MT100
Rated Operating Capacity (SAE)
1000 lbs
Operating Weight
3390 lbs
Ground Pressure (Rubber)
5.2 psi
Auxiliary Std Flow
11 gpm
Width
35.6 in
Height to Bucket Hinge Pin
80.9 in
BobQuote
MT100
Engine
MT100
Horsepower
24.8 hp
Gross HP
25 hp
Net HP
23.3 hp
Displacement
54.9 cubic in
Starter Horsepower
3.6 hp
Number of Cylinders
3
Fuel Consumption
1.1 gph
Performance
MT100
Rated Operating Capacity (SAE)
1000 lbs
Ground Pressure (Standard Tracks)
5.3 psi
Ground Pressure (Optional Tracks)
4 psi
Tipping Load
2898 lbs
Operating Weight
3390 lbs
Travel Speed
4.1 mph
Travel Speed - High
4.1 mph
Travel Speed - Low
4.1 mph
Travel Speed - Reverse
2.9 mph
Ground Pressure (Rubber)
5.2 psi
Capacities
MT100
Fuel Tank
7 gal
Cooling System
7 qt
Engine Oil with Filter
3.8 qt
Hydraulic Reservoir
2.5 gal
Hydraulic System
MT100
Pump Capacity
12 gpm
System Relief @ Quick Couplers
2900 psi
Auxiliary Std Flow
11 gpm
Raise Lift Arm
2.9 sec
Lower Lift Arm
2 sec
Bucket Dump
1.6 sec
Bucket Rollback
1.4 sec
Dimension
MT100
Length
106.2 in
Overall Length in Travel Position
84.5 in
Width
35.6 in
Height
54.6 in
Overall Height
54.6 in
Height to Bucket Hinge Pin
80.9 in
Operating Height
54.6 in
Max Dump Height
80.9 in
Reach @ Maximum Height
18.6 in
Rollback Angle
22 deg
Length of track on ground
41.4 in
Track Width
7.1 in
Track Width - Optional
9.8 in
Controls
MT100
Instrumentation
MT100
Fuel Gauge
Gauge
Hourmeter
Gauge
Features
MT100
Parking Brake
Standard
Lift-Arm Support
Standard
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Wide Track
Optional
Neutral Start Interlocks
Standard
Lift Arm Lockout With Manual Bypass
Standard
Tilt Lockout
Standard
Built-In Tie Down & Crane/Lift Locations
Standard
Drive System
MT100
Main Drive
Fully hydrostatic rubber track drive
Price
MT100
Additional Product Information
MT100
