Specs
L28 Key Specifications
L28
Horsepower
24.8 hp
Rated Operating Capacity (ISO) (Articulated)
1222 lbs
Rated Operating Capacity (ISO) (Straight)
1534 lbs
Operating Weight
4195 lbs
Auxiliary Std Flow
11.4 gpm
Width (over tires)
46.5 in
BobQuote
L28
SSL Specs
L28
Engine
L28
Horsepower
24.8 hp
Alternator (text)
90 A OPEN FRAME WITH INTERNAL REGULATOR
Battery Size
12 VOLT BCI GROUP 26 540 AMPS COLD CRANKING CAPACITY AT 0 F (-18 C) 80 MINUTE RESERVE CAPACITY
Fuel Consumption
1.1 gph
Turbocharged Engine
no
Performance
L28
Rated Operating Capacity (ISO) (Articulated)
1222 lbs
Rated Operating Capacity (ISO) (Straight)
1534 lbs
ROC with Counterweight Option - Articulated
1475 lbs
ROC with Counterweight Option - Straight
1952 lbs
Tipping load - Articulated
2444 lbs
Tipping Load - Straight
3068 lbs
Operating Weight
4195 lbs
Travel Speed
8.3 mph
Capacities
L28
Fuel Tank
9.6 gal
Hydraulic System
L28
Cylinder Extend Bore
2.2 in
Cylinder Extend Rod
1.2 in
Pump Type
ENGINE DRIVEN GEAR TYPE
System Relief @ Quick Couplers
2900 psi
Auxiliary Std Flow
11.4 gpm
Control Valve - Type
MANUALLY OPERATED SERIES TYPE (LIFT & TILT FUNCTIONS) WITH FLOAT DETENT ON LIFT. E/H OPERATED PARALLEL TYPE ( AUX & TELESCOPIC FUNCTIONS).
Cylinders: Lift - Bore
2.8 in
Cylinders: Lift - Rod
1.5 in
Cylinders: Lift - Stroke
16.5 in
Cylinders: Tilt - Bore
2.5 in
Cylinders: Tilt - Rod
1.5 in
Cylinders: Tilt - Stroke
13.3 in
Dimension
L28
Height to Bucket Hinge Pin - Extended
104.4 in
Height to Bucket Hinge Pin - Retracted
85.4 in
Inside Turning Radius
78.2 in
Outside Turning Radius
100.9 in
Articulation Angle
43 deg
Length without Attachment
93.2 in
Length with Standard Bucket
122.4 in
Width (with bucket)
50 in
Width (over tires)
46.5 in
Dump Angle @ Maximum Height
40 deg
Reach @ Maximum Height
30.9 in
Ground Clearance
5.5 in
Wheelbase
47.2 in
Tire Size
23X10.5-12, 8 PLY
Controls
L28
Instrumentation
L28
Features
L28
Front and Rear Work Lights
Standard
Air Conditioning
Not Applicable
Backup Alarm
Standard
Cab Enclosure
Optional
Cab Heater
Optional
Operating Lights
Optional
Rear Window
Optional
Rotating Flashing Beacon
Optional
Lift-Arm Support
Standard
Grab Handles
N/A
Suspension Seat
Standard
Turn Signals
Optional
Two Speed Travel
Not Applicable
Deluxe Instrumentation
Not Applicable
Hydraulic Bucket Positioning
Standard
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Tires-Ply Rating
8
Cup Holder
Standard
Horn
Standard
Serviceability
L28
Drive System
L28
Main Drive
Hydrostatic drive with 4 individual drive motors
