Specs
L23 Key Specifications
L23
Horsepower
24.8 hp
Rated Operating Capacity (ISO) (Articulated)
1159 lbs
Rated Operating Capacity (ISO) (Straight)
1395 lbs
Operating Weight
3790 lbs
Auxiliary Std Flow
11.4 gpm
Width (over tires)
43.2 in
BobQuote
L23
SSL Specs
L23
Engine
L23
Horsepower
24.8 hp
Alternator (text)
90 AMP VENTILATED
Battery Size
12 VOLT BCL GROUP 26 540 AMPS COLD CRANKING CAPACITY AT 0F (-18 C) 80 MINUTE RESERVE CAPACITY
Fuel Consumption
1.1 gph
Turbocharged Engine
no
Performance
L23
Rated Operating Capacity (ISO) (Articulated)
1159 lbs
Rated Operating Capacity (ISO) (Straight)
1395 lbs
ROC with Counterweight Option - Articulated
1471 lbs
ROC with Counterweight Option - Straight
1815 lbs
Tipping load - Articulated
2317 lbs
Tipping Load - Straight
2789 lbs
Operating Weight
3790 lbs
Travel Speed
8.2 mph
Capacities
L23
Fuel Tank
9.6 gal
Hydraulic System
L23
Pump Type
Engine Driven Gear Type
System Relief @ Quick Couplers
2900 psi
Auxiliary Std Flow
11.4 gpm
Control Valve - Type
MANUALLY OPERATED SERIES TYPE (LIFT & TILT FUNCTIONS) WITH FLOAT DETENT ON LIFT. E/H OPERATED PARALLEL TYPE (AUX FUNCTIONS).
Cylinders: Lift - Bore
2.8 in
Cylinders: Lift - Rod
1.5 in
Cylinders: Lift - Stroke
16.5 in
Cylinders: Tilt - Bore
2.5 in
Cylinders: Tilt - Rod
1.5 in
Cylinders: Tilt - Stroke
13.3 in
Dimension
L23
Height to Bucket Hinge Pin - Extended
85.4 in
Inside Turning Radius
77.2 in
Outside Turning Radius
100.9 in
Articulation Angle
43 deg
Length without Attachment
93.2 in
Length with Standard Bucket
122.4 in
Width (with bucket)
44 in
Width (over tires)
43.2 in
Dump Angle @ Maximum Height
40 deg
Reach @ Maximum Height
16.8 in
Ground Clearance
5.5 in
Wheelbase
47.2 in
Tire Size
23X8.5-12
Controls
L23
Instrumentation
L23
Features
L23
Front and Rear Work Lights
Standard
Air Conditioning
Not Applicable
Backup Alarm
Standard
Cab Enclosure
Optional
Cab Heater
Optional
Operating Lights
Optional
Rear Window
Optional
Rotating Flashing Beacon
Optional
Lift-Arm Support
Standard
Grab Handles
N/A
Suspension Seat
Standard
Turn Signals
Optional
Two Speed Travel
Not Applicable
Deluxe Instrumentation
Not Applicable
Hydraulic Bucket Positioning
Standard
Auxiliary Hydraulics
Standard
Spark Arrestor Muffler
Standard
Bob-Tach Attachment System
Standard
Tires-Ply Rating
10
Cup Holder
Standard
Horn
Standard
Serviceability
L23
Drive System
L23
Main Drive
Hydrostatic pump driving 4 independent wheel motors
