Specs
E165 Key Specifications
E165
Operating Weight
38,376 lb
Bucket Digging Force
25,794 lbf
Maximum Reach at Ground Level
345.6 in
Width
102 in
Tail Swing Type
Conventional
Engine
E165
Emissions Tier (EPA)
Tier 4
Engine Fuel
Diesel
Turbocharged Engine
yes
Optional Turbocharged Engine
N/A
Performance
E165
Operating Weight
38,376 lb
Weight Class
17 t
Travel Speed - High
3.1 mph
Travel Speed - Low
1.9 mph
Arm Digging Force
18,077 lbf
Bucket Digging Force
25,794 lbf
Maximum Dig Depth
240 in
Max Dump Height
255.6 in
Maximum Reach at Ground Level
345.6 in
Capacities
E165
Fuel Tank
77.1 gal
Hydraulic System
E165
Auxiliary Pressure
4,694 psi
Total Hydraulic Flow
80.4 gal/min
Dimension
E165
Length
325.2 in
Width
102 in
Height
120 in
Height with Operator Cab
115.2 in
Features
E165
Air Conditioning
Standard
Cab Enclosure
Standard
Heater Air Conditioning
Standard
Radio
Standard
Tail Swing Type
Conventional
Auxiliary Hydraulics
Standard
Quick Tach System
Optional
Rubber Track
Not Applicable
Selectable Auxiliary Hydraulic Flow
Standard
Dozer Blade
Not Applicable
