Specs
CT1025 Key Specifications
CT1025 HSTD <!-->
Horsepower
24.5 hp
Lift Capacity at 24" behind Lift Point
700 lb
PTO HP
18.8 hp
Transmission Type
Infinite, 2 Range Hydrostatic -->
Width
45.7 in
Turning Radius
8' 3"
Wheelbase
4' 7"
Engine
--> CT1025 HSTD <!-->
Emissions Tier (EPA)
Tier 4 -->
Horsepower
24.5 hp
Displacement
61 in³
Number of Cylinders
3 <!-->
Gross HP
24.5 hp
Engine Model
3C100LFH-U1 -->
Performance
<!--> CT1025 HSTD -->
Operating Weight
1,521 lb
Travel Speed
11 mph
Travel Speed - Reverse
7.5 mph
3-Point Hitch
Category 1 <!-->
3-pt Lift Control Type
Hydraulic Position Control System -->
Lift Capacity at 24" behind Lift Point
700 lb
Rear PTO System
Independent <!-->
Rear PTO - RPM
540 -->
PTO HP
18.8 hp
Mid PTO - RPM
2200 <!-->
Capacities
--> CT1025 HSTD <!-->
Fuel Tank
6.7 gal
Hydraulic System
--> CT1025 HSTD <!-->
Implement Hydraulic Flow
4.6 gal/min
Total Hydraulic Flow
6.4 gal/min
Steering Hydraulic Flow
1.8 gal/min
Drive System
--> CT1025 HSTD <!-->
Brake Type
Wet Multi Disc -->
Transmission Type
Infinite, 2 Range Hydrostatic <!-->
Dimension
--> CT1025 HSTD <!-->
Length
99.3 in
Width
45.7 in
Height
87.6 in
Ground Clearance
6.3 in
Turning Radius
8' 3"
Wheelbase
4' 7"
Front Tire Size
Front Industrial (AG, Turf) 18X8.5-10 (18X8.5-10,18X8.5-10 ) -->
Rear Tire Size
Rear Industrial (AG, Turf) 26X12-12 (26X12-12,26X12-12 ) <!-->
Loader Attachment
--> CT1025 HSTD <!-->
Loader Lift Height
6' 0"
Lift Capacity at Bucket Pivot
608 lb
Bucket Width
4' 0"
